Linear Actuator
Model LA4xxA
Operating voltage options: 12Vdc or 24VdcStroke options: 50, 100, 200, 300, 400, 500, 600mmNo Load Speed: 10mm/secMaximum Force: 750NClosed length: (Stroke+130mm)Open length: (2xStroke+130mm)Ingress protection rating: IP53
Operating voltage options: 12Vdc or 24VdcStroke options: 50, 100, 200, 300, 400, 500, 600mmNo Load Speed: 10mm/secMaximum Force: 750NClosed length: (Stroke+130mm)Open length: (2xStroke+130mm)Ingress protection rating: IP53
Model LA4xxD
Operating voltage options: 12Vdc or 24VdcStroke options: 100, 200, 300, 400, 500mmNo Load Speed: 4mm/secMaximum Force: 1200NClosed length: (Stroke+120mm)Open length: (2xStroke+120mm)Ingress protection rating: IP65
Operating voltage options: 12Vdc or 24VdcStroke options: 100, 200, 300, 400, 500mmNo Load Speed: 4mm/secMaximum Force: 1200NClosed length: (Stroke+120mm)Open length: (2xStroke+120mm)Ingress protection rating: IP65
- Model LA1xx
- Operating voltage options: 12Vdc or 24Vdc
- Stroke options: 100, 200, 300, 400, 500mm
- No Load Speed: 12mm/sec
- Maximum Force: 3000N
- Closed length: (Stroke+175mm)
- Open length: (2xStroke+175mm)
- Ingress protection rating: IP44
Model LA5xx
Operating voltage options: 12Vdc or 24Vdc Stroke options: 100, 200, 300, 400mmNo Load Speed: 80mm/secMaximum Force: 150NClosed length: (Stroke+235mm)Open length: (2xStroke+235mm)Ingress protection rating: IP54
Operating voltage options: 12Vdc or 24Vdc Stroke options: 100, 200, 300, 400mmNo Load Speed: 80mm/secMaximum Force: 150NClosed length: (Stroke+235mm)Open length: (2xStroke+235mm)Ingress protection rating: IP54
